Сетевая камера Axis P1353 BAREBONE 0523-041 P1353 BAREBONE в Перми

Vendor Code	P1353 BAREBONE

General
Device Type	Network camera (no lens)
Connectivity Technology	Wired
Approximate Width	3.1 in
Approximate Depth	5.9 in
Approximate Height	1.8 in
Approximate Weight	1.3 lbs
Camera
Type	Color - Day&Night - fixed
Digital Video Format	MJPEG, H.264
Max Digital Video Resolution	800 x 600
Exposure Range	2 sec
Minimum Illumination	0.1 lux - color - F1.00.02 lux - B&W - F1.0
Video Capture	800 x 600 @ 30 fps
Audio Support	Yes : two-way audio capability, built-in microphone
RAM	256 MB
Flash Memory	128 MB
Features	Motion sensor, backlight compensation, IR filter , sharpness control, white balance, auto exposure control, color control, progressive scanning, brightness control, contrast control, e-mail alerts, image mirror, ONVIF support, Lightfinder technology, digital PTZ function, SDXC-card slot
Image Sensor
Type	CMOS 1/3"
Lens Construction
Type	CS-mount
Focus Adjustment	Automatic
Interfaces
Networking	Ethernet 10Base-T/100Base-TX - DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, IPv4, IPv6, Bonjour, RTCP, SMB, IGMP, QOS, CIFS
Alarm Inputs Qty	1
Alarm Outputs Qty	1
Expansion / Connectivity
Interfaces	1 x network / power - Ethernet 10Base-T/100Base-TX - RJ-451 x audio - line-in/microphone - mini-phone 3.5 mm1 x audio - line-out - mini-phone 3.5 mm
Miscellaneous
Included Accessories	Stand
Compliant Standards	C-Tick, EN 61000-3-2, EN 61000-3-3, EN55024, CISPR 22, EN55022 Class B, ICES-003 Class B, EN 61000-6-1, FCC Part 15 B, EN 61000-6-2, UL 60950-1, IEC 60950-1, EN 60950-1, VCCI Class B
Color	White
Power
Power Requirements	DC 8 - 28 V / PoE
Software / System Requirements
Software Included	Drivers & Utilities
Manufacturer Warranty
Service & Support	3 years warranty
Service & Support Details	Limited warranty - 3 years
Environmental Parameters
Min Operating Temperature	32 °F
Max Operating Temperature	122 °F
Relative Humidity (operating)	10 - 80% (non-condensing)

General

Device Type

Network camera (no lens)

Connectivity Technology

Wired

Approximate Width

3.1 in

Approximate Depth

5.9 in

Approximate Height

1.8 in

Approximate Weight

1.3 lbs

Camera

Type

Color - Day&Night - fixed

Digital Video Format

MJPEG, H.264

Max Digital Video Resolution

800 x 600

Exposure Range

2 sec

Minimum Illumination

0.1 lux - color - F1.00.02 lux - B&W - F1.0

Video Capture

800 x 600 @ 30 fps

Audio Support

Yes : two-way audio capability, built-in microphone

RAM

256 MB

Flash Memory

128 MB

Features

Motion sensor, backlight compensation, IR filter , sharpness control, white balance, auto exposure control, color control, progressive scanning, brightness control, contrast control, e-mail alerts, image mirror, ONVIF support, Lightfinder technology, digital PTZ function, SDXC-card slot

Image Sensor

Type

CMOS 1/3"

Lens Construction

Type

CS-mount

Focus Adjustment

Automatic

Interfaces

Networking

Ethernet 10Base-T/100Base-TX - DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, IPv4, IPv6, Bonjour, RTCP, SMB, IGMP, QOS, CIFS

Alarm Inputs Qty

Alarm Outputs Qty

Expansion / Connectivity

Interfaces

1 x network / power - Ethernet 10Base-T/100Base-TX - RJ-451 x audio - line-in/microphone - mini-phone 3.5 mm1 x audio - line-out - mini-phone 3.5 mm

Miscellaneous

Included Accessories

Stand

Compliant Standards

C-Tick, EN 61000-3-2, EN 61000-3-3, EN55024, CISPR 22, EN55022 Class B, ICES-003 Class B, EN 61000-6-1, FCC Part 15 B, EN 61000-6-2, UL 60950-1, IEC 60950-1, EN 60950-1, VCCI Class B

Color

White

Power

Power Requirements

DC 8 - 28 V / PoE

Software / System Requirements

Software Included

Drivers & Utilities

Manufacturer Warranty

Service & Support

3 years warranty

Service & Support Details
